550cm orca hypalon large sunbath panel inflatable rib boat rib550 with teak floor luxury
This boat is with large sunbed , best choice for relax and sightviewing !!!
Rib550 panga boat continues the elegant European styling and a sporty wide-body frame, the panga boat rib550 is sure to exceed your expectations in both form and function. Luxury design and equipments for best comfort and great experience .
Rigid inflatable boat (RIB) is a light boat constructed with a solid, shaped hull and flexible tubes at the gunwale. Featuring stable design, high performance and high capacity, it is a development of the inflatable boat. The inflatable collar allows the vessel to maintain buoyancy even if a large quantity of water is shipped aboard due to bad sea conditions.
1. Technical Data :
| Model | Length(cm) | Beam(cm) | Hull length(cm) | Hull width(cm) | No.of chamber | Tube Dia.(cm) | Max persons | Engine power(HP) | Net weight(kgs) | Packing size(cm) |
| RIB550 | 550 | 246 | 505 | 200 | 5 | 54 | 10 | 115 | 490 | 520*210*110 |
2. Standard fittings :
center console with cushions(including windshield,4 point switch ,oil gauge),
seat box(with cushions and SS frame roll) , bow box,steering system,sewage pump,
90L Built-in fuel tank ,100A battery with battery box,
bandage , anchor and anchor rope ,
fiberglass archor tray ,fiberglass arch with navigation lights
,stainless steel sunshade,shower facility ,
built-in water tank , clean water pump , stainless steel ladder, etc
3. Optional Equipments :
boat trailer ,fiberglass step , etc.
4. Other Features :
All our inflatable boats use 0.9mm or1.2mm , 1100 denier polyester fabric that has been specially coated on both sides with PVC. It is proven to be immensely strong, tear resistant and waterproof. This provides a boat that is virtually unaffected by weather (excesses of heat, cold or humidity), fuel, oil, strong sunlight and everyday abrasion.
The chemical formula that is used to make the outside PVC layer gives the following tolerances & qualities:
-
Abrasion resistance and airtight properties: 200*170 N/5cm +20
-
Temperature resistance: -30 to +70 centigrade
-
Chemical resistance: hydrocarbon, sunlight, seawater, oil and fuel
-
Dimensional stability: 1% (24 hrs, 70 centigrade)
-
Tensile and tear strength: 3800*3550 (+250)
Construction:
-
Polyurethane glue is used to cold glue all our seams
-
Every boat is made by hand
-
Four layers of reinforced seams are used to ensure strength
Warranty:
-
Hull fabric: 5 years
-
Hull seams: 3 years
5. Warranty :
We also provide excellent after-sale services and 3 - 5 year (3 years for PVC , 5 years for Hypalon )
warranty of the hull and materials.Each boat comes with a repair kit containing the maintenance tools and materials(fabrid and glue).The replacement parts will be offered for free within warranty period.In the event that the boat has really quality defects within warranty period,we will offer free replacement parts after the receipt of the related pictures and descriptions supporting the factor； In case of serious quality problems ,a replacement boat will be sent to the customers with next order shipment.
